Introduction to the
current mainstream rail welding technology
Arc welding technology is the most widely used rail welding technology at present. It uses arc light generated by electrodes to heat and melt rail steel, and then welds two rails together through pressure. This technology has the advantages of simple operation, low cost and high efficiency, and has been widely used in railway construction.
02Gas shielded welding technology
Gas shielded welding technology is a welding method that uses inert gas or active gas as a protective medium. In rail welding, commonly used gases are argon and carbon dioxide. This technology can effectively prevent impurities in the air from entering the weld, thereby improving the quality and strength of the weld.
03Laser welding technology
Laser welding technology is a non-contact welding method under a high-energy density heat source, which can achieve fast, precise and damage-free rail connection. The laser beam can directly penetrate the rail steel, causing it to melt quickly and form a uniform connection. This technology has the advantages of fast welding speed, small heat-affected zone, and high weld quality, but the equipment cost is relatively high.
04Friction welding technology
Friction welding technology is a method of welding through friction heat on the surface of rail steel. It does not require an external heating source, but generates high temperature through friction between rail steels, causing them to melt and form a connection. This technology has the advantages of energy saving and environmental protection, fast welding speed, and high weld quality, but requires special equipment and process control.
05Electron beam welding technology
Electron beam welding technology is a method that uses high-energy electron beams to heat and melt rail steel. It can achieve precisely controlled heating and deep penetration to obtain a uniform connection. This technology has the advantages of high efficiency, high quality, and low deformation, but the equipment cost is relatively high.
The current mainstream rail welding technologies include arc welding, gas shielded welding, laser welding, friction welding, and electron beam welding. Each technology has its own characteristics and scope of application. In railway construction, the appropriate welding method can be selected according to the specific situation. With the continuous development of science and technology, rail welding technology is also constantly improving. In the future, more and more advanced welding methods may appear to provide more reliable and efficient support for railway construction.
Case analysis of the application of
rail welding technology in railway construction
01High-speed railway line welding technology
With the construction of high-speed railways, the requirements for line quality and safety are getting higher and higher. The traditional rail connection method requires bolts to fix, which is prone to loosening and wear, affecting the operation of trains. The use of rail welding technology can achieve seamless connection and improve the stability and durability of the line. For example, laser welding technology is used on the Beijing-Shanghai high-speed railway, making the line connection more firm and greatly improving the safety of train operation.
02Light rail line welding technology
Compared with traditional heavy railways, light rail lines are more suitable for urban transportation. However, due to the dense urban traffic and complex environment, traditional rail connection methods are difficult to meet the needs. Therefore, arc welding technology is widely used in urban light rail construction. This method can complete welding in a short time, and the welding points are smoother, reducing noise and vibration during train driving.
03High-speed rail bridge welding technology
With the continuous expansion of the high-speed rail network, more and more high-speed rail bridges are also being built. In bridge construction, the use of traditional rail connection methods will have an adverse effect on the bridge structure. Therefore, the use of rail welding technology can effectively solve this problem. For example, on the Guangzhou-Shenzhen high-speed railway line, a special resistance welding technology is used to make the railway and bridge connection more closely and avoid damage to the bridge structure.
04Track maintenance welding technology
With the increase in railway transportation volume, track maintenance has also become very important. The traditional rail connection method requires the removal of the original bolts and the re-fixation of new bolts, which is time-consuming and labor-intensive. The use of track welding technology can quickly complete the maintenance work and improve the stability and safety of the line. For example, arc welding technology is used for maintenance work on the Wuhan-Guangzhou high-speed railway, which greatly shortens the maintenance time and saves labor costs.
Advantages and Challenges of
Track Welding Technology
The development of track welding technology has brought many advantages to railway construction, but also some challenges. In this introduction, we will explore the advantages and challenges brought by track welding technology and understand its importance to railway construction.
01Improve the speed of railway construction
The traditional railway track laying method requires the track to be spliced and then fixed, which is a very time-consuming process. With track welding technology, the two tracks can be directly welded together, which greatly shortens the track laying time and improves the speed of railway construction.
02Reduce maintenance costs
The traditional railway splicing method is prone to problems such as breakage and loosening, and requires frequent maintenance and replacement. The use of track welding technology can effectively avoid these problems and reduce maintenance costs.
03Improve operation safety
Since the two tracks connected by track welding technology form a whole, there will be no breakage or loosening at the splicing, thereby ensuring the safety of train operation.
The traditional railway splicing method requires a certain amount of space to place connectors and bolts, while the use of track welding technology can save this part of space, thereby saving land resources.
However, track welding technology also faces some challenges.
01High technical requirements
Orbital welding technology requires superb welding technology and precise equipment, and has high requirements for operators. Therefore, when using orbital welding technology, a professional team is required to operate, which increases the cost and difficulty.
Orbital welding equipment is expensive and requires professional personnel to maintain and service it. Therefore, the use of orbital welding technology will increase the cost of railway construction.
03Limited scope of application
Due to the size limitations of orbital welding equipment, it is currently only applicable to straight railways and some curved railways. For railways with complex curves or special shapes, this technology cannot be used.
Application of
welding structure in high-speed railway
Flash welding, gas pressure welding and other welding methods are used to connect rails into continuous seamless lines to improve the stability and safety of train travel.
High-speed railway bridges are mostly steel structures, and beam splicing, reinforcement and maintenance are achieved through welding technology.
Station platforms, canopies and other steel structures also widely use welding technology to ensure the stability and aesthetics of station structures.
Market demand and technical challenges
Market demand:
With the rapid development of high-speed railways, the demand for welded structures continues to increase, requiring welding technology to be more efficient, environmentally friendly and intelligent.
Technical challenges:
High-speed railway welded structures face complex and changeable working conditions and extreme environmental tests, and need to solve key technical problems such as welding deformation, cracks, and fatigue. At the same time, it is also necessary to improve the level of welding automation and intelligence to reduce production costs and labor intensity.
Selection and performance requirements of
welding materials
Types and characteristics of common welding materials
Welding rods:
Applicable to manual arc welding, including carbon steel, low alloy steel, stainless steel and other materials, with good welding process performance and mechanical properties.
Welding wires:
Applicable to automatic or semi-automatic gas shielded welding, including solid welding wires and flux-cored welding wires, with high efficiency and excellent welding quality.
Flux:
Used in processes such as submerged arc welding and electroslag welding, through cooperation with welding wires or welding rods, a stable arc and excellent weld formation are obtained.
Material performance indicators and test methods
Chemical composition:
Ensure that the chemical composition of the welding material meets the standard requirements, avoid undesirable organization and performance, and use spectral analysis and other methods for testing.
Mechanical properties:
Including tensile strength, yield strength, elongation and other indicators, tested by tensile test.Including tensile strength, yield strength, elongation and other indicators, tested by tensile test.
Welding process performance:
Including arc stability, spatter rate, weld formation and other indicators, tested by welding process assessment.
Material selection
principles and practical application cases
Material selection principles:
Select suitable welding materials and processes according to factors such as the material, thickness, and welding position of the parent material.
Practical application cases:
For example, in the welding of high-speed railway track plates, flux-cored wire and automatic gas shielded welding processes were selected to improve production efficiency and welding quality. At the same time, corresponding welding process parameters and operating procedures were formulated for different parent material materials and thicknesses to ensure the stability and reliability of the welded structure.
Welding method selection and comparison
Arc welding:
Suitable for thicker plates, with high weld quality, but relatively low efficiency
Laser welding:
Suitable for high-speed welding of thin plates with small heat-affected zone and small deformation, but high requirements for equipment.
Friction stir welding:
Suitable for welding materials such as aluminum alloys, no filler material is required, but the welding speed is slow.
Electron beam welding:
Suitable for welding high-melting-point metals and dissimilar alloys, with a large weld depth-to-width ratio, but high equipment cost
Process parameter
setting and optimization method
Selection and matching of welding current, voltage, speed and other parameters to ensure welding quality and efficiency
Adopt intelligent welding system to monitor the welding process in real time and automatically adjust process parameters.
Optimize welding sequence to reduce thermal deformation and residual stress.
Use preheating and post-heat treatment to improve the weldability of materials and improve weld quality.
Which welding materials are used for
welding railway tracks?
The commonly used welding materials for welding railway tracks are copper-aluminum welding wire, copper-aluminum welding rod, and ferrite welding rod. The selection method is determined according to the track material and requirements.
01 Commonly used welding material types
Copper-aluminum welding wire
Copper-aluminum welding wire is a copper-based welding material, the main components of which are copper and aluminum. It has the characteristics of low melting point, good fluidity and high reliability. Copper-aluminum welding wire is used for welding railway tracks and can meet the requirements of wear resistance, pressure resistance, corrosion resistance and stability of the tracks.
Copper-aluminum welding rod
Copper-aluminum welding rod has similar characteristics to copper-aluminum welding wire and is also a reliable welding material. Copper-aluminum welding rod and welding wire control weld formation and are used for welding railway tracks.
Ferrite welding rod
Ferrite welding rod is a high-quality welding material. In addition to high strength, excellent corrosion resistance, wear resistance and high temperature resistance, it also has good welding performance and can be used to weld various railway track materials.
02 Selection method
The materials of railway tracks are generally low-carbon steel, low-alloy steel and high-carbon steel. Different materials and different requirements require different welding materials. When selecting welding materials, the following factors can be considered comprehensively according to the material of the track and the welding process requirements:
◆ Mechanical properties and durability of the welded joint
◆ Chemical composition and mechanical properties of the filler metal and the base material
◆ Welding cost
◆ Environmental conditions and process requirements for welding
◆ Availability and ease of use of welding materials
According to different requirements and different situations, suitable welding materials can be selected to ensure the quality and performance of the welded joint.
03 Characteristics and applicability of various welding materials
Copper-aluminum welding wire
Copper-aluminum welding wire has a low melting point, good fluidity, and good weld formation. It is suitable for welding thinner metal plates, metal wires and other types of welding.
Copper-aluminum welding rod
Copper-aluminum welding rod has good plasticity and forgeability. It is suitable for welding thicker metal materials and large structural parts. It can produce uniform welds and high-strength joints.
Ferrite welding rod
Ferritic welding rod has high strength, corrosion resistance, wear resistance and high temperature resistance. It is suitable for welding various railway track materials and can maintain the stability and firmness of the weld under pressure and temperature changes.
