Customize E7018 Welding ELECTRODE RODS

Iron powder type basic electrode GB/T 5117 E5018 AWS A5.1 E7018 ISO 2560-B-E4918 A

PDF DOWNLOAD
Product Detail
Tag

Production Description

Iron powder type basic electrode

GB/T 5117 E5018

AWS A5.1 E7018

ISO 2560-B-E4918 A

AWS E7018 is basic coated iron powder low potassium hydrogen type electrode. Both AC and DC can be used and can be all-position welding. It can reach  excellent welding performance, good arc stiffness,little spatter, easy slag removal and good weld appearance,high deposition efficiency.Weld metal has excellent plasticity and low temperature toughness



It can improve deposition efficiency because of the iron powder in the coating. Its arc is more stable with less spatter.It is easy to remove the residue. It can provide both beautiful welding line shape and good deposited metal mechanical performance.And the current can be AC or DC.It can be used for all position welding.



WELDING POSITIONS:

PA, PB, PC, PD, PE, PF.

X-ray flaw detection: Ⅰ level.



E7018 has excellent welding performance, excellent operating performance, easy reignition, stable arc and beautiful appearance of weld.



We has devoting ourselves to producing and trading for 10 years,establishing a good relationship with the company of US,Canada, Mid east  MARKET and so on. As a professional manufacturer, our factory began to produce welding wire since 2010. ER70S-6 welding wire and welding electrode E6013 E7018 E6010 E6011 is our main product. We also supply aluminum welding wire,stainless steel welding wire, flux cored wire, surfacing welding wire,copper alloy welding wire and welding accessories.

Please Contact me

Different sizes, different prices. Contact me for more details!

24 hours online for you~

Chemical Composition:

C

Mn

Si

S

P

≤0.12

≤1.6

≤0.75

≤0.035

≤0.035



Mechanical Property:

AWS A5.1

Tensile Strength

Rm

Yield Strength

Rel

Elongation

A

Akv

KV2

MPa

MPa

%

J

0 degree/J

E7018

≥490

≥400

≥22

≥27

-30

Customize E7018 Welding ELECTRODE RODS

Specification & Package

2.0mm (5/64”) x 300mm,   2.5kgs/box, 20kg(8boxes) per carton.

2.5mm (3/32”) x 300/350mm;   2.5kgs/box, 20kg(8boxes) per carton.

3.2mm (1/8”) x 350mm;        5kgs/box, 20kg(4boxes) per carton.

4.0mm (5/32”) x 400mm;       5kgs/box, 20kg(4boxes) per carton.

5.0mm x 450mm; other size please contact our service.



OEM/ODM Package Available:

NW: 20.00KG,GW: 20.40KG,

we also can do different kgs package, plastic bag package,

we can print the package as your requests, we have professional designer to make the package design with your brand & LOGO.
